Sony Starvis 2 IMX676 – 12.61 MP CMOS Sensor for Security Cameras

The IMX676AACR1-C is a 12.61 MP RGB CMOS sensor offering high resolution and 60 fps frame rate, ideal for security camera applications requiring detailed imaging and high sensitivity.

The Sony Starvis 2 IMX676AACR1-C is a high-performance 12.61 MP CMOS image sensor, designed for security camera applications that demand high resolution and superior image quality. Featuring a diagonal 10.04 mm (Type 1/1.6) optical size and a 3552 x 3552 pixel array, this sensor captures detailed and sharp images even in low-light environments. Its 2.0 µm pixel size ensures high sensitivity and accurate color reproduction, enhanced by the RGB primary color mosaic filters. The IMX676AACR1-C operates with analog 3.3 V, digital 1.1 V, and interface 1.8 V power supplies, ensuring efficient power consumption during continuous surveillance. Equipped with a rolling shutter and an electronic shutter with variable charge-integration time, this sensor is ideal for capturing fast-moving objects without distortion. With a maximum frame rate of 60 fps, the IMX676AACR1-C is suitable for high-speed video capture, making it perfect for professional-grade security systems. Packaged in a ceramic LGA with 132 pins, this sensor is designed for durability and reliability in demanding security environments.
