Eliminate Motion Artifacts

Global Shutter for Embedded Vision

When motion demands accurate image data - not just recognizable images.

Talk to an Expert
Buy on Mouser
Global Shutter for Embedded Vision
The Core Problem

A distorted image is not just a visual problem

In embedded vision, a camera is rarely just capturing images for people to view. It is capturing data that machines use to detect, measure, navigate, align, inspect, and react.

That changes how image quality needs to be understood. In a fast-thinking embedded system, distortion can become bad input data. It can affect object detection, feature tracking, localization, robotic guidance, barcode reading, dimensional inspection, or the confidence of an AI model running at the edge.

This is why global shutter technology matters.

How It Works

Every pixel. Same moment.

When the camera, object, robot, drone, vehicle, or conveyor is moving, the timing of image capture becomes critical. Rolling shutter sensors capture an image line by line. For many applications, this is perfectly acceptable.

But when motion is fast enough, the time difference between the first and last rows of the image can create skew, stretch, wobble, or shape distortion. The image may still look recognizable, but the geometry of the scene is no longer captured at one single moment in time.

Global shutter sensors solve this by exposing all pixels at the same time. The result is a frame that better preserves the position and shape of moving objects. For embedded systems that rely on visual data to make real-time decisions, that difference can be significant.

Why It Matters

Global shutter is about data integrity

The common way to explain global shutter is to compare it with rolling shutter. That explanation is accurate, but it does not fully explain why global shutter is important in embedded vision.

In a machine vision or edge AI system, the image is often passed directly into software that must make a decision. A robot may need to calculate the position of a moving object. A drone may need to track features in the environment for navigation. A logistics system may need to read a code on a fast-moving package. A traffic system may need to identify a license plate on a moving vehicle.

In each case, the camera is not simply documenting what happened. It is providing input for a real-time system response.

Key insight

If the frame is distorted, the downstream algorithm may be forced to interpret inaccurate geometry - a square object may appear skewed, a feature point used for tracking may not align with its true location, a fast-moving target may be detected but its position unreliable.

Interactive simulation

Sensor readout: what each pixel actually captures

Watch each sensor read its pixels while an object moves through the scene. The bottom row shows the actual captured frame your algorithm receives. Select object speed to see how readout timing determines data quality.

Object speed
Rolling shutter Row by row
Captured frame
Global shutter All pixels simultaneously
Captured frame
System consequence: Select an object speed to see how readout timing affects the captured result.
Rolling Shutter Artifacts

Where rolling shutter can become a problem

Rolling shutter is widely used for good reasons - high-resolution imaging, strong low-light performance, compact designs, cost-effective systems. In many embedded vision applications, it is the right choice. The challenge appears when there is fast relative motion between camera and scene.

Artifact

Skewed vertical lines

Straight edges appear angled when the camera or object moves horizontally during readout.

Artifact

Stretched or compressed objects

Objects appear taller or shorter than they are, depending on direction of motion during exposure.

Artifact

Distorted rotating parts

Spinning components such as fans, wheels, or propellers appear warped or bent.

Artifact

Unstable scene geometry

Feature points shift position across the frame, making localization and measurement unreliable.

Interactive simulation

Conveyor & logistics: how rolling shutter corrupts geometry

A package moves along a conveyor belt. Both sensors watch the same scene. Raise belt speed to see rolling shutter geometry corruption — and what it means for the downstream algorithm.

Belt speed
m/s
Rolling shutter Distorting
Skew offset0px
Bbox error0%
Barcode read--
Global shutter Clean frame
Skew offset0px
Bbox error0%
Barcode readOK
System consequence: Select a belt speed to see downstream algorithm impact.
Where It Matters Most

Applications where global shutter delivers

The common thread is not simply speed. The common thread is whether motion can affect the reliability of the data extracted from the image.

Robotics & automation

Object detection, localization, navigation, picking, sorting. AMRs, AGVs, humanoids, warehouse robots - real-time decisions while moving through the environment.

Drones & UAVs

Navigation, mapping, landing assistance, obstacle detection, inspection, visual positioning. Critical when camera motion and vibration are present during flight.

Intelligent transportation

License plate recognition, traffic monitoring, vehicle classification, tolling, enforcement and roadside analytics where vehicles move quickly through the scene.

Motion analysis & science

Sports analytics, life sciences, and research imaging where high-speed movement must be captured without geometric distortion for accurate measurement.

Interactive simulation

Readout timing: why row offset matters for your application

Each row on a rolling shutter sensor fires at a different moment in time. Select your application to see how that timing offset corrupts the geometry your algorithm receives - and how global shutter eliminates it.

Rolling shutter Rows offset in time
Exposure window
Object position at capture
Reconstructed shape (distorted)
Global shutter All rows - same instant
Exposure window
Object position at capture
Reconstructed shape (accurate)
System consequence: Select an application scenario above.
Interactive simulation

Drone & UAV: vibration-induced wobble distortion

A drone camera captures a structured scene with visual feature points used for SLAM navigation. Rolling shutter reads each row at a different moment — vibration turns that into wobble. Select an intensity level to see what the nav algorithm actually receives.

Vibration intensity
Rolling shutter Wobble distortion
Wobble amplitude0px
Feature drift0px
SLAM reliability--
Global shutter Stable frame
Wobble amplitude0px
Feature drift0px
SLAM reliabilityHigh
System consequence: Select a vibration level to see navigation algorithm impact.
Beyond the Sensor

What to consider for a complete vision system

A global shutter sensor is only one part of a reliable embedded vision system. To get strong performance, engineering teams also need to consider the optical path, mechanical integration, embedded platform, software stack, and production requirements.

For AI-enabled systems, image consistency can be just as important as image capture. If exposure, color, sharpness, noise, or focus vary too much, model performance can become less predictable.

This is where FRAMOS approaches global shutter as part of the complete embedded vision pipeline – from sensor selection to system integration with less risk. That includes sensor expertise, module design, lens pairing, geometric calibration services, open-source drivers, and platform support across leading embedded platforms.

Need help with integration or configuration?

Our engineering team can help you select the right module, interface, lens and driver setup for your platform.

Request a Quote
01

Lens selection & optics

Field of view, distortion, sharpness, light transmission, and depth of field all affect what the sensor delivers.

02

Lighting & exposure

Determines whether motion is frozen clearly enough for the algorithm, avoiding motion blur at the pixel level.

03

Interface & bandwidth

Ensures the required resolution and frame rate can move reliably into the processing system.

04

Driver & ISP support

Determines whether the camera integrates efficiently into the target platform without months of bringup.

05

Geometric calibration

Critical when camera geometry must be well understood for localization, measurement, or multi-camera systems.

Camera Modules

FRAMOS global shutter modules for embedded vision

FRAMOS offers global shutter camera modules for teams building embedded vision systems where motion accuracy, integration speed, and image data reliability matter.

Recommended starting point

Product image representative only

Resolution 3.2 MP
Sensor Sony IMX900 (Pregius S)
Optical format 1/3.1"
Pixel size 2.25 µm
Shutter Global shutter
Availability Mouser (distribution)
FSM:GO IMX900
Accessible global shutter for embedded vision

FSM:GO IMX900 is the recommended starting point for most motion-critical applications. It brings together Sony Pregius S global shutter performance, a complete FSM:GO module design, lens options, platform support, and fast access through distribution – several things that are usually difficult to get in one embedded vision module.

Sony is widely recognized for high-performance global shutter sensor technology, but products built around these sensors have traditionally been expensive, engineering-heavy, or difficult to integrate into embedded systems. FSM:GO IMX900 changes that equation. At a price point comparable to other entry-level global shutter options, engineering teams get a complete system-ready module with validated sensor integration, lens options, standardized interfaces, and support for NVIDIA Jetson, NXP, Qualcomm, and Raspberry Pi. Open-source drivers and ISP support are included.

Many embedded vision teams do not want to spend months building the camera stack before they can evaluate their actual product idea. FSM:GO is designed for exactly that – connect, bring up the image pipeline, validate image quality, and start testing. Available through Mouser for fast access in lower quantities.

Validated Platform Support
NVIDIA Jetson
Qualcomm Platform
NXP Processors
Raspberry Pi Compute
Production-Ready
Scales directly from validation to mass-produced deployments.
Pre-Integrated
Includes custom optics, lens options, and calibrated ISP tuning.
Buy on Mouser View product

Product image representative only

Resolution 24.5 MP
Sensor Sony IMX530
Pixel array 5320 × 4600
Pixel size 2.74 µm
Interface SLVS-EC (8-lane)
FSM-IMX530
24.5 MP high-resolution with SLVS-EC

Designed for applications where motion accuracy, high resolution, and fast image data transfer are all required. The SLVS-EC interface with 8 data lanes enables high-resolution global shutter imaging for demanding machine vision, inspection, robotics, and traffic applications.

SLVS-EC integration can be complex for teams working with FPGA-based processing, custom carrier boards, or high-bandwidth architectures. FRAMOS offers its own SLVS-EC IP and deep Sony sensor integration expertise – a strong partner when SLVS-EC is part of the system design.

View product

Product image representative only

Resolution 5.1 MP
Sensor Sony IMX568
Pixel array 2472 × 2064
Pixel size 2.74 µm
Interface MIPI CSI-2 (4-lane)
Variants Color & monochrome
FSM-IMX568
5.1 MP global shutter for higher detail

For applications that need more resolution than IMX900 while staying in a compact global shutter format, FSM-IMX568 is a strong option. It provides additional image detail while maintaining the distortion-free capture needed for motion-sensitive embedded vision.

Available in color and monochrome with C/CS mount options. Well suited for robotics, industrial inspection, logistics automation, and machine vision where objects are moving but additional spatial detail is required.

View product

Product image representative only

Resolution 2.8 M
Sensor Sony IMX421
Optical format 2/3"
Pixel size 4.5 µm
Interface SLVS, SLVS-EC (8L)
FPS 409
FSM-IMX421
High-FPS Global Shutter with 8-Lane SLVS-EC

FSM-IMX421 is a strong option for applications where frame rate is the priority. The module features Sony’s IMX421 Pregius global shutter sensor, providing 1944 × 1472 resolution and frame rates up to 409 fps. With support for SLVS-EC over 8 lanes, FSM-IMX421 is built for high-speed image capture where fast data transfer is critical. This makes it well suited for motion analysis, high-speed inspection, robotics, industrial automation, and machine vision systems where events happen quickly and the image pipeline needs to keep up.

For teams building FPGA-based systems, FRAMOS can support both the sensor module integration and the SLVS-EC implementation through our own SLVS-EC IP and Sony sensor expertise.

View product

Product image representative only

Resolution 12.4 MP
Sensor Sony IMX304
Form factor 28 × 28 mm
Interface LVDS (8-lane)
Max frame rate 23 fps
FSM-IMX304
Sub-LVDS / LVDS for specialized architectures

A specialized global shutter option for embedded and industrial architectures that require LVDS sensor connectivity. While many embedded vision systems today are built around MIPI CSI-2, some industrial, FPGA-based, and custom processing designs rely on LVDS-style connectivity.

FSM-IMX304 provides access to proven Sony global shutter performance in a module format suited for specialized image acquisition pipelines – when the sensor interface is part of the architecture decision.

Module selector

Choosing the right global shutter module

The right module depends on the application, resolution requirement, motion conditions, lens requirements, processing platform, and integration path.

Find the right module for your application

Answer three quick questions and we'll show you which FRAMOS global shutter module fits your requirements.

What resolution do you need?
What interface does your platform use?
What matters most for your project?
Show full comparison table
Module Resolution Interface Best fit for Availability
FSM:GO IMX900
Recommended 		3.2 MP MIPI CSI-2 / GMSL Robotics, drones, AMRs, AGVs, smart devices - fast evaluation, practical deployment Mouser (distribution)
FSM-IMX568 5.1 MP MIPI CSI-2 Applications needing more resolution while maintaining global shutter under motion FRAMOS direct
FSM-IMX530 24.5 MP SLVS-EC High-resolution inspection, measurement, industrial vision - FPGA / high-bandwidth FRAMOS direct
FSM-IMX304 12.4 MP LVDS Specialized architectures requiring LVDS connectivity and FPGA-based image pipelines FRAMOS direct

Global shutter is a system-level decision

FRAMOS helps engineering teams select the right sensor, module, lens, interface, driver, image pipeline, and integration approach for the application.
