Your Application. Our Lens.

Image Quality Starts with the Right Lens

FRAMOS provides a curated lens portfolio, complemented by filters, coatings, and polarization options. The portfolio covers a wide range of use cases, from standard off-the-shelf lenses to application-specific custom lens & optical design.

Talk to an expert
Image Quality Starts with the Right Lens

Lenses Selected, Verified, and Supported by FRAMOS


FRAMOS goes beyond supplying optics, every lens is selected, verified, and fully managed to perform in your system. With engineering led from Europe and controlled manufacturing and quality oversight, we deliver optics you can rely on for consistent, repeatable image performance at scale.

<strong><strong><strong>Lenses Selected, Verified, and Supported by FRAMOS</strong></strong></strong>
FRAMOS goes beyond supplying optics, every lens is selected, verified, and fully managed to perform in your system. With engineering led from Europe and controlled manufacturing and quality oversight, we deliver optics you can rely on for consistent, repeatable image performance at scale.
  • Lenses selected and matched to your sensor and application, backed by FRAMOS engineering
  • Fully managed sourcing and supplier control for consistent quality and availability
  • Reduced integration risk through validated optics and system alignment
  • Reliable, repeatable image performance at scale
Custom Lens Design

Qualified Lenses for best performance with FRAMOS sensor modules

FRAMOS provides a curated portfolio of qualified lenses covering different fields of view aligned with FRAMOS sensor modules, ensuring reliable optical performance across a wide range of use cases.

<strong>Qualified Lenses for best performance with FRAMOS sensor modules</strong>FRAMOS provides a curated portfolio of qualified lenses covering different fields of view aligned with FRAMOS sensor modules, ensuring reliable optical performance across a wide range of use cases.
  • Qualified lenses optimized for FRAMOS modules
  • Wide field-of-view options across applications
  • Validated for real-world performance and reliability

Lenses Product Lineup

Loading...

Filters

Filters

Mount

Image Circle [mm]

Resolution [MP]

Focal Length [mm]

Aperture

Field of View Horizontal [°]

Active Filters

Products

A list of available products with their attributes.

Placeholder

DSL146A-NIR-F1.4-TOF NIR Lens for Time-of-Flight and IR Applications

IR-optimized lens for 1/2.8" sensors in NIR range.
Mount–Image Circle [mm]–Resolution [MP]–Focal Length [mm]–Aperture–Field of View Horizontal [°]–View Product
Placeholder

FLP-HM-045-03-v-00 High-Performance Lens for Imaging Applications - 4.5 mm F2.7 M12 8 MP

This M12-mount lens provides 8 MP resolution with a 4.5 mm focal length and an F2.7 aperture, optimized for sensors with an image diagonal of up to 11.1 mm.
MountM12Image Circle [mm]11.1Resolution [MP]8Focal Length [mm]4.5Aperture2.7Field of View Horizontal [°]100View Product
Placeholder

FLP-HM-043-01-v-00 High-Quality Lens for Imaging Applications - 4.25 mm F1.8 M12 2 MP

This M12-mount lens provides 2 MP resolution with a 4.25 mm focal length and an F1.8 aperture, optimized for sensors with an image diagonal of up to 8.8 mm.
MountM12Image Circle [mm]8.8Resolution [MP]2Focal Length [mm]4.25Aperture1.8Field of View Horizontal [°]116View Product
Placeholder

FLP-HM-037-00-v-01 High-Performance Lens for Imaging Applications - 3.7 mm F1.7 M12 8 MP

This M12-mount lens provides 8 MP resolution with a 3.7 mm focal length and an F1.7 aperture, optimized for sensors with an image diagonal of up to 9.4 mm.
MountM12Image Circle [mm]9.4Resolution [MP]8Focal Length [mm]3.7Aperture1.7Field of View Horizontal [°]125View Product
Placeholder

FLP-HM-034-04-v-00 High-Resolution Lens for Imaging Applications - 3.42 mm F3 M12 5 MP

This M12-mount lens provides 5 MP resolution with a 3.42 mm focal length and an F3 aperture, optimized for sensors with an image diagonal of up to 7.54 mm.
MountM12Image Circle [mm]7.54Resolution [MP]5Focal Length [mm]3.42Aperture3Field of View Horizontal [°]103View Product
Placeholder

FLP-HM-033-05-v-00 High-Quality Lens for Imaging Applications - 3.31 mm F1.5 M12 4 MP

This M12-mount lens provides 4 MP resolution with a 3.31 mm focal length and an F1.5 aperture, optimized for sensors with an image diagonal of up to 7.1 mm.
MountM12Image Circle [mm]7.1Resolution [MP]4Focal Length [mm]3.31Aperture1.5Field of View Horizontal [°]109View Product
Placeholder

flp-hm-032-05-v-00 High-Quality Lens for Imaging Applications - 3.15 mm F2.4 M12 2 MP

This M12-mount lens provides 2 MP resolution with a 3.15 mm focal length and an F2.4 aperture, optimized for sensors with an image diagonal of up to 7 mm.
MountM12Image Circle [mm]7Resolution [MP]2Focal Length [mm]3.15Aperture2.4Field of View Horizontal [°]111View Product
Placeholder

flp-hm-030-05-v-00 High-Quality Lens for Imaging Applications - 3 mm F1.8 M12 4 MP

This M12-mount lens offers 4 MP resolution with a 3 mm focal length and an F1.8 aperture, optimized for sensors with an image diagonal of up to 7.2 mm.
MountM12Image Circle [mm]7.2Resolution [MP]4Focal Length [mm]3Aperture1.8Field of View Horizontal [°]110View Product
Previous Next

Not Sure Which Lens Type Is Right for Your Project?

Our experts will help you select the best lens format based on your sensor, system size, and imaging goals. Whether you're scaling production or prototyping a custom module, FRAMOS provides expert consultation and integration support from concept to deployment.

Talk to an expert
