Sony ECX342A 0.64-inch QXGA OLED Microdisplay
Sony ECX342A OLED Microdisplay provides sharp, high-contrast visuals for head-mounted displays and portable monitors.
Product Overview
Sony ECX342A offers high-resolution QXGA visuals in a compact 0.64-inch OLED panel.
The Sony ECX342A is a 0.64-inch diagonal active matrix OLED panel, featuring a QXGA resolution of 2048 x 1536 pixels. Built on single crystal silicon transistors, it integrates both panel and logic drivers, delivering high image quality with a brightness of up to 1000 cd/m2 and a contrast ratio of 100,000:1. The ECX342A is suitable for head-mounted displays, electronic viewfinders, and other compact, high-resolution display applications where clarity and sharpness are essential.
Product Specifications
-
Interface - LVDS, Sub-LVDS
-
Chromatics - RGB
-
Contrast - 100000 : 1
-
Diagonal [mm] - 16
-
Diagonal [inch]
- 0.64
- no
- 60
-
Manufacturer - Sony
-
Max. luminance [cd/m2] - 1000
-
Power supply [V] - '-5/+5V (analog), 1.8V (logic)
-
Product Type - Active color matrix OLED Display
-
Resolution [Pixel] - 2040 x RGB x 1536
-
Resolution Type
- Quad XGA
