Sony Starvis 2 IMX678 – 8.29 MP CMOS Sensor for Security Cameras

Description

The Sony IMX678AAQR1-C is a high-performance CMOS image sensor from the Sony Starvis 2 series, optimized for security camera applications. With a diagonal size of 8.86 mm (Type 1/1.8 inch) and 8.40 million effective pixels, this sensor is designed to deliver high-definition imaging in various lighting conditions, including low-light environments. Leveraging advanced Starvis 2 technology, the IMX678AAQR1-C ensures high sensitivity, low dark current, and no smear, making it an excellent choice for security and surveillance systems.

Offering a resolution of 3840 x 2160 pixels, the IMX678AAQR1-C delivers 4K Ultra HD quality imaging, with a compact pixel size of 2 x 2 μm for enhanced light sensitivity. It uses RGB primary color mosaic filters to ensure accurate color reproduction and crisp, clear images. The sensor operates efficiently with a triple power supply (analog 3.3 V, digital 1.1 V, and interface 1.8 V), balancing high performance with low power consumption, ideal for energy-sensitive applications such as battery-operated security systems.

Key features of the IMX678AAQR1-C include:

• 8.40 MP resolution (3840 x 2160)
• 2 x 2 μm pixel size for high sensitivity and clear imaging
• Triple power supply (3.3V, 1.1V, 1.8V) for efficient power usage
• High sensitivity and low dark current for excellent low-light performance
• Electronic shutter with variable charge-integration time
• MIPI interface for fast and reliable data transmission
• Ceramic LGA package for enhanced durability and system integration

The IMX678AAQR1-C is especially well-suited for security camera applications, where low-light performance and high image clarity are critical. The sensor’s high sensitivity allows it to capture detailed images in dim lighting, making it ideal for nighttime surveillance or environments with limited light. Its rolling shutter and electronic shutter with variable charge-integration time ensure accurate image capture under varying light conditions, maintaining image quality in dynamic environments.

With its 2 x 2 μm pixel size, the IMX678AAQR1-C delivers enhanced light-gathering capabilities, ensuring that it performs well in both high and low-light conditions. The sensor’s MIPI interface allows for fast and efficient data transmission, making integration into modern security systems easier. Additionally, the durable ceramic LGA package ensures reliability and longevity, making this sensor suitable for long-term use in both indoor and outdoor security systems.

The Sony IMX678AAQR1-C combines advanced Starvis 2 technology, high-resolution imaging, and low-light capabilities, making it a powerful solution for a variety of security and surveillance applications. Whether used for residential, commercial, or public security, this sensor provides the precision, speed, and reliability required for today’s demanding security environments.
